A system that receives signals from all sensors in a space (emergency · lights · fire · security) and sends text messages over the internet to registered numbers
Emergency calls, access control, fire detection and switch operation detection for seniors living alone were all needed at once.
A safety system with remote checking using easy-to-install self-powered sensors, and text alerts for prolonged (24 / 48 / 72-hour) inactivity, were needed.
Emergency bellEmergency call
Fire detection sensorFixed-temperature
Door sensorOpen / Close
Wireless switchON / OFF
RepeaterMWSR2-900 · Optional
Sensor HubMWSH-300
Text alertsManager's mobile phoneRanges are based on open field with no obstacles. Each added repeater extends the range by approx. 1 km.
Model MWSR2-900
| Size | W115 × D115 × H30 mm |
|---|---|
| Weight | 167 g |
| Frequency | 920.7 / 447.9 MHz (FSK) |
| Antenna | External antenna × 2 |
| Tx/Rx range | approx. 1 km (open field) |
| Range extension | +approx. 1 km (open field) |
| Display | FND 3-digit, LED (Rx · Tx · Power) |
| Power | DC 12 V 1 A adapter |
Model MWSH-300
| Size | W100 × D100 × H26 mm |
|---|---|
| Weight | 145 g |
| Frequency | 920.7 / 447.9 MHz (FSK) / Wi-Fi |
| Antenna | External antenna × 2, Internal antenna × 1 |
| Reception range | approx. 1 km (open field) |
| Recipient numbers | max. 5 |
| Display | FND 4-digit, Power · Rx · Tx LED |
| External terminals | Power, TCP/IP, LAN (RS485) |
| Power | DC 9 V 1 A adapter |
Emergency bells, fire detection sensors, door sensors and wireless switches are installed in the bedroom, bathroom, living room and kitchen, and the Sensor Hub sends text messages to guardians and caregivers.
Emergency calls, access, fire and switch operation sent by text to guardians and caregivers
Self-powered sensors installed anywhere without wiring work
Inactivity alert texts sent after prolonged (24 / 48 / 72-hour) inactivity
CONTACT MPIA
Smart Safety Alert Platform
A system that receives signals from all sensors in a space (emergency · lights · fire · security) and sends text messages over the internet to registered numbers
